Key Applications
Virtualization, HPC, Cloud Computing, High End Enterprise Server, Software
Defined Storage, Application Tier Service Provider, 5G/Telco,
Key Features
Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable Processors;
Intel® C621A Chipset;
32 DIMM Slots; Up to 8TB DRAM; Up to 8TB Intel® Optane™ Persistent
Memory (up to 12TB with DRAM); 3200/2933/2666 ECC DDR4
LRDIMM;RDIMM; Intel® Optane™ Persistent Memory 200 series;
1 PCIe 4.0 x16 (LP)
1 PCIe 4.0 x16 (FH, 10.5"L)
5 PCIe 4.0 x8 (FH, 10.5"L)
1 internal PCIe 4.0 x8 (in x16 slot, LP);
Flexible networking options;
6x 2.5" hot-swap hybrid NVMe/SATA/SAS drive bays;
6 heavy duty fans with optimal fan speed control;
1600W redundant Titanium level power supplies;
| Form Factor | 2U Rackmount Enclosure: 437 x 89 x 574mm (17.2" x 3.5" x 22.6") Package: 625 x 253 x 1154mm (24.6" x 9.96" x 45.43") |
| Processor | Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processors Up to 40C/80T; Up to 60MB Cache per CPU |
| GPU | Max GPU Count: Up to 4 double-width or 6 single-width GPUs Supported GPU: NVIDIA PCIe: T4, RTX A6000, RTX A5000, A40, A30, A16, A2, A100, A10 |
| System Memory | Slot Count: 32 DIMM slots Max Memory (2DPC): Up to 8TB 3200MT/s ECC DDR4 RDIMM/LRDIMM Supports Intel® Optane™ persistent memory 200 series |
| Drive Bays Configuration | Default: Total 6 bays 6 front hot-swap 2.5" NVMe/SAS*/SATA drive bays (*SAS support may require additional storage controller and/or cables) |
| Expansion Slots | Default 1 PCIe 4.0 x16 FH/10.5"L slot 5 PCIe 4.0 x8 FH/10.5"L slots 1 PCIe 4.0 x8 LP slot 1 PCIe 4.0 x16 LP slot |
| On-Board Devices | SATA: SATA (6Gbps) ; RAID 0/1/5/10 support NVMe: NVMe; RAID 0/1/5/10 support Chipset: Intel® C621A Network Connectivity: 2 RJ45 10GBASE-T with Intel® X710-AT2 (optional) 2 RJ45 10GBASE-T with Intel® X710-TM4 (optional) 2 SFP+ 10GbE with Intel® X710-TM4 (optional) No NIC option supported |
| Power Supply | 1x 1600W Redundant Titanium Level (96%) Hot-plug power supply |
| Dimensions and Weight | Weight: Gross Weight: 66 lbs (30 kg) Net Weight: 40 lbs (18.2 kg) Available Color: Black Front & Silver Body |
